HARDWARE SPECIFICATIONS:
CPU: AMLogic S905W Quad Core Cortex-A53 up to 2.0 Ghz
GPU: Pental-Core Arm Mali 450
Memory: 2 GB DDR3
Flash: 16GB eMMC
WIFI: Built-in 2.4GHz WiFi 802.11 B/G/N
LAN: 100Mbps Ethernet
POWER SUPPLY SPECIFICATIONS:
Power Supply (Adapter) DC 5V/2A
Power Indicator (LED) Power “On”: Blue / Standby: Red.
OTHER:
1x 5V DC Input Jack
Remote Receiver
Power LED
PRODUCT SPECIFICATIONS
Length: 95mm
Width: 95mm
Height: 18mm
OPERATING SYSTEM:
ZaapTV™ OS based on Android 7.1
CONNECTIVITY:
2x USB Socket
1x HDMI 2.0 Socket
1x Audio/Video analog output
1x LAN Ethernet 100Mbps
1x Built-in WIFI
Stream Support | RTSP, RTP, HTTP, UDP, IGMP etc. |
DRM | Google Widevine, HDCP 2.2, Secure OS 2.0 |
Video Processing | H264 |
Video Codecs | H.265, H.264 AVC, H.264, MVC, MPEG-1,MPEG-2 SD/HD, MPEG-4 SD/HD, ASP, VC-1/WMV, AVS/AVS+, MJPEG, HEVC HD, UHD |
Video Containers | MKV, WMV, MPG, MPEG, DAT, AVI, MOV, ISO, MP4, RM and JPG |
Audio Codecs | MPEG 2 Audio, AAC, MP3, WMA, RM, FLAC, OGG MP3, AAC, WMA, RM, FLAC, Ogg, Dolby Digital, Dolby Digital Plus, DTS |
HD video output | Full HD max. 1920×1080 pixels |
AUDIO OUT | |
---|---|
Audio Digital-to-analog converter | 192kHz/24-bit |
S/N Ratio | Min.80dBx2ch |
Digital audio output | HDMI |
VIDEO OUT | |
---|---|
Video output signal | NTSC and PAL TV system |
Analog video output | CVBS |
Digital video output | HDMI |
ACCESSORIES:
Instruction Manual
110V/240V Power adaptor with US/EU/UK/AU plug
ZAAPTV IR Remote Control
AV Cable
HDMI Cable
REQUIREMENTS:
* We recommend an ADSL2+ connection with an Internet Speed of 6Mbps and above.
* For best streaming performance we also suggest a fixed Ethernet cable connection between the ZAAPTV device and the modem
* If you are unable to install the ZAAPTV device with an Ethernet connection and your ZAAPTV device is more than 6-7m from the modem, then we recommend a Powerline Adaptor.
To buy a Powerline Adaptor from our store, click on the link below:
TP-LINK AV600 Nano Powerline Adapter Starter Kit Model: TL-PA411KIT
Many things can interfere with your modem’s Wi-Fi signal and this can significantly affect the performance of your ZAAPTV device creating buffering and freezing problems whilst streaming your Favourite Greek or Arabic TV Channels.
If you are experiencing Buffering or Freezing problems, we suggest you read the following article found in our Support Pages: What can cause interference with Wi-Fi
Manufacturers Warranty: 12 Months
ZAAPTV Service: 2 Years and are Subject to the Terms and Conditions and Disclaimer notices, specifically information under the headings THE SERVICE AND PRICES and PRODUCTS OR SERVICES (if applicable) which states “ZaapTV does not offer any streaming services and cannot make any guarantees to channel content or any network or internet related issues.”
Product Support: This item comes with Email only support through the Ticketing System available on the ZaapTV.com.au website.
If you require Full product support, this can be purchased by selecting the Extended Warranty option. Full Product Support will give you access to Email, Website and Phone Support for the life of the ZAAPTV Service which will be 2 years unless otherwise noted.
For all Support and Technical problems, visit our Support Pages:
Frequently Asked Questions (FAQ’s)
Product Activation
Helpful Videos
If you need to Activate your Device or Activate your Subscription and require assistance, please complete the Authorise Device or Activate Subscription tab under the ZaapTV Contact Us page: https://zaaptv.com.au/contact/
If what you are looking for is not available here, you will have to place a Support Ticket.
For VIP Support Customers, call our Office during Business Hours on 03 9005 5401 and select Option 2
ZAAPTV HD809/HD709/HD609 Updates:
Software Updates
Articles you may be interested in:
Freezing and Buffering problems?
Streaming problems? Hotspot your ZAAPTV Device to your Mobile Phone
Getting the most out of your IPTV Receiver for best streaming
Do I need to upgrade my modem?
Full product details available from ZAAPTV.com
https://www.zaaptv.com/hd809n
ZAAPTV Channel List
https://www.zaaptvgroup.com/channels
External links listed above are direct links to ZAAPTV and associated websites. Some channels are not available in Australia. If you are unsure of any channels, please contact our office to confirm channel availability.
THE BEST IPTV RECEIVER JUST GOT BETTER
Watch your favorite Live TV Channels and use your favorite Apps!
What if you could watch thousands of Live TV channels from every corner of this world with just the click of a button? With the new ZaapTV™ HD809N you can now make it happen! Live channels, Radio stations, Video On Demand content, Apps and lots of more new features now await you to explore!
PACKED FULL AMAZING FEATURES COMES WITH KODI™ PRE-INSTALLED
ZAAPTV™ MARKET FOR APPS
With our dedicated ZaapTV™ Market, you can download and install amazing new apps on your ZaapTV™ HD809N device! Over a 1000 apps for News, Movies, Series, Social Networks, Games and many more. More amazing content for everyone!
EASY TO USE REMOTE CONTROL
Our brand new Remote Control, provides all the controls necessary to enjoy a full experience of the ZaapTV™ HD809N and all its features. Zaap through our Channels, Apps or browse the internet with ease!
NOW WITH PARENTAL CONTROL
One of the most asked for features is here. Protect your kids from accessing adult or graphic content.
